Manual stamping machine PT 11

Effort-saving and quick marking of single or small-series parts - even mobile.

  • Mark up to 5 characters into steel and up to 11 characters into aluminum
  • Tool-free operation through pulling of the operating lever
  • Stageless adjustable power of impact for perfect results
  • Different heights of work pieces can be marked with a single adjustment

Number of characters that can be marked (approximate value)

Depending on font size and material (steel St 37/aluminium)

Font sizePT 11PT 18PT 30
1,5 mm51430
2,0 mm41226
2,5 mm31119
3,0 mm2917
4,0 mm1815
5,0 mm1612
Font sizePT 11PT 18PT 30
1,5 mm112670
2,0 mm102465
2,5 mm82260
3,0 mm62055
4,0 mm51650
5,0 mm41446

The mentioned values are approximate values. You have doubts, that the stamping machine is sufficient for your requirements? Please send us your material sample. We check your requirements in practical use.



You want to mark more characters?

Technical data

  PT 11PT 18PT 30

Max. power of impact

kN

63065

Tool fitting

mm

Ø8 x 32

Ø10 x 45

Ø16 x 45

Total stroke / Useable stroke

mm

30 / 22

60 / 45

80 / 55

Weight

kg

10

3083

Dimensions (w x h x d)

mm

140x210x450

250x340x765

280x443x650

Bearing surface table

mm

100x100

160x160

242x242

T-Notch size

mm

6

10

12

Outreach till middle of tool

mm

80

130

190

Max. work height (without tool)

mm

260

330

370

Spindle feeder

mm

8

15

25
