Handstempelgerät PT 25
Handstempelgerät PT 25

INQUIRE NOW – So you can mark your products permanently and fraud-resistant!

  • Send your inquiry fast and uncomplicated now.

Pneumatic hand-stamping tool PT 25

Quickly mark parts with pneumatic strike.

  • Mark up to 7 characters into steel and up to 8 characters into aluminum
  • Operation as handheld tool or integration into production lines
  • Ergonomic work through single blow-back proof impulse as well as low weight
  • Stageless adjustable power of impact for perfect results
  • Quick, tool-free change of stamps

Number of characters that can be marked (approximate value) PT 25

Depending on font size and material (steel St 37/aluminium)

Font sizePT 10PT 22PT 25
1,5 mm347
2,0 mm346
3,0 mm235
4,0 mm124
5,0 mm013
Font sizePT 10PT 22PT 25
1,5 mm568
2,0 mm568
3,0 mm457
4,0 mm346
5,0 mm236

The mentioned values are approximate values. You have doubts, that the hand-stamping tool is sufficient for your requirements? Please send us your material sample. We check your requirements in practical use.



Technical data PT 25

  PT 10PT 22PT 25
Required air pressurebar2-62-62-6
Connection G 1/8“G 1/8“G 1/4“
Impact forcekNca. 10ca. 20ca. 40
Length with stamp (ca.)mm260320340
Diametermm253240
Weight with stampkg0,51,01,8
